Breakout Cabling for 400G/800G: 1x2, 1x4 and 1x8 Topologies
A breakout cable splits one high-speed parallel port into several lower-speed ports. There are three common topologies. 1x2: an 800G port becomes two 400G ports, using an MPO-16 to 2× MPO-12 assembly or a dual MPO-12 module. 1x4: a 400G DR4 port becomes four 100G DR ports, using an 8-fiber MPO-12 APC to 4× LC duplex harness. 1x8: an 800G DR8 port becomes eight 100G DR ports, using an MPO-16 APC to 8× LC duplex harness. Breakout works only with parallel optics (SR4, DR4, SR8, DR8), never with FR4 or LR4, and the switch must support the breakout mode.
Breakout lets you connect a high-radix spine or leaf switch to many lower-speed servers or switches, reuse existing 100G optics during a migration, and use every lane of an expensive 800G port. This guide explains the three topologies, the cable for each, the fiber-to-lane mapping and the common mistakes.
Why Breakout Works
A parallel optic sends each lane on its own fiber pair. Each lane is an independent link at the lower speed, so the lanes can go to different destinations:
- 400GBASE-DR4 has 4 lanes of 100G. A 400G DR4 module can run as 4×100G breakout to 100G DR modules, according to transceiver vendor datasheets.
- 800GBASE-DR8 has 8 lanes of 100G and supports 2×400G DR4, 4×200G DR2 and 8×100G DR1 breakouts on modules that offer them.
- 400GBASE-SR8 modules can be configured for 2×200G-SR4, and channelized versions for 8×50G-SR.
FR4 and LR4 optics multiplex all lanes onto one fiber pair, so they cannot be split by a cable. Breakout is also a switch feature: the port must be configured for the breakout mode, and the far-end optics must use the same lane type, modulation and FEC.
The Three Topologies
| Topology | Example | Host connector | Far-end connectors | Cable |
|---|---|---|---|---|
| 1x2 | 800G DR8 → 2× 400G DR4 | MPO-16 APC | 2× MPO-12 APC | MPO-16 to 2× MPO-12 conversion assembly |
| 1x2 | 800G 2×DR4 → 2× 400G DR4 | 2× MPO-12 APC | 2× MPO-12 APC | Two standard MPO-12 APC cables |
| 1x4 | 400G DR4 → 4× 100G DR | MPO-12 APC | 4× LC duplex | 8-fiber MPO-12 to 4× LC harness |
| 1x4 | 100G SR4 → 4× 25G SR | MPO-12 UPC | 4× LC duplex | 8-fiber MPO-12 to 4× LC harness (multimode) |
| 1x8 | 800G DR8 → 8× 100G DR | MPO-16 APC | 8× LC duplex | MPO-16 to 8× LC harness |
1x2: One 800G Port to Two 400G Ports
The 1x2 breakout keeps parallel optics at both ends. Each 400G DR4 leg uses 8 fibers (4 transmit, 4 receive).
- If the 800G module has one MPO-16 port, use an MPO-16 to 2× MPO-12 conversion assembly. Fibers 1–4 and the matching receive fibers go to one MPO-12; fibers 5–8 and their receive fibers go to the other.
- If the 800G module has two MPO-12 ports (2×DR4 or 2×SR4 versions), no special cable is needed: run two standard 8-fiber MPO-12 cables.
This is the cleanest way to connect 800G spines to 400G leaves. See Designing an 800G link with MPO-16.
1x4: One 400G Port to Four 100G Ports
The 1x4 breakout is the most common. A 400G DR4 module on an MPO-12 APC port connects to four 100G single-lane modules with duplex LC.
On a 400G DR4 MPO-12 interface, transmit lanes 1–4 are on fibers 1–4 and receive lanes are on fibers 9–12, with RX1 on fiber 12. Fibers 5–8 are unused. So the harness pairs:
| LC duplex leg | Transmit fiber | Receive fiber |
|---|---|---|
| Leg 1 | 1 | 12 |
| Leg 2 | 2 | 11 |
| Leg 3 | 3 | 10 |
| Leg 4 | 4 | 9 |
The same mapping applies to 40G SR4 → 4×10G and 100G SR4 → 4×25G breakouts on multimode, with UPC instead of APC.
1x8: One 800G Port to Eight 100G Ports
On an MPO-16 interface, transmit lanes 1–8 are on fibers 1–8 and receive lanes 8 to 1 are on fibers 9–16 (RX1 on fiber 16). An MPO-16 to 8× LC harness pairs:
| Leg | Tx | Rx | Leg | Tx | Rx |
|---|---|---|---|---|---|
| 1 | 1 | 16 | 5 | 5 | 12 |
| 2 | 2 | 15 | 6 | 6 | 11 |
| 3 | 3 | 14 | 7 | 7 | 10 |
| 4 | 4 | 13 | 8 | 8 | 9 |
An 800G DR8 port can then feed eight 100G DR servers or switches. All 16 fibers of the MPO-16 are used.
Direct Harness or Structured Breakout?
There are two ways to build a breakout:
- Direct harness. One cable with the MPO at one end and LC legs at the other. Best inside a rack or between adjacent racks. Simple, lowest loss (no extra mated pairs).
- Structured breakout. An MPO trunk runs between rows to an MPO-to-LC cassette or a harness in a panel; LC patch cords connect to the equipment. Best for longer runs and for changes, because you repatch at the panel instead of pulling harnesses. It adds mated pairs, so check the loss budget.
See what is an MTP-LC cassette and MPO insertion loss budget.
Polarity, Gender and End Face
- Gender: transceiver MPO ports are pinned (male), so the MPO end of a harness that plugs into a module must be female. If the MPO end plugs into a panel adapter instead, match it to the trunk on the other side.
- Polarity: the harness itself must pair each transmit fiber with its receive fiber as in the tables above. If the breakout passes through a trunk, the total channel must keep that pairing; see MPO polarity Type A, B, C.
- End face: single-mode DR4 and DR8 MPO ports are APC. Single-lane 100G LC modules use UPC duplex LC, so a single-mode breakout harness is normally APC at the MPO end and UPC at the LC end. See APC vs UPC.
Choosing Leg Lengths and Labels
- Stagger leg lengths to match the port positions on the far-end switch or server, so cords do not loop or strain.
- Label each leg with the lane number and destination port; with 8 legs, a swapped pair is hard to find later.
- Match the switch's breakout port order. Lane 1 does not always map to the lowest-numbered sub-port; check the switch documentation and label to match.
- Keep bend radius at the fan-out; use protected fan-out transitions for tight racks.
Common Breakout Mistakes
- Trying to break out an FR4 or LR4 module. These multiplex the lanes optically; no cable can split them.
- Mismatched optics. A 400G DR4 port must break out to 100G single-lane PAM4 optics (DR type), not older 100G optics that use a different modulation or wavelength plan.
- Wrong end face. APC at the module, UPC at a UPC module; never mate APC with UPC.
- Wrong gender. A male MPO harness end will not mate with a pinned module.
- Port not configured. The switch port must be set to the breakout mode before the links come up.
Huawellux Breakout Assemblies
Huawellux manufactures breakout cabling for 400G and 800G:
- MPO and MTP® to LC harnesses in 8 and 12 fibers (OS2 G.657.A1 or G.657.A2, OM4, OM5), MPO end UPC or APC and male or female, LC end UPC or APC, 0.5 m to 3.5 m, with 0.2 m, 0.3 m or 0.5 m branch length options and custom stagger, mapping and labels.
- MPO-12 and MTP-12 to 2× MPO-4/MTP-4 (8F) and 3× MPO-4/MTP-4 (12F) harnesses in OS2 G.657.A1 or G.657.A2, OM4 and OM5, UPC or APC, male or female on both ends, 0.5 m to 3.5 m, for splitting 8- and 12-fiber MPO legs into 4-fiber interfaces.
- Made to order: MPO-16 to 8× LC harnesses for 1x8 breakouts, MPO-16 to 2× MPO-12 conversion assemblies for 1x2 breakouts.
- MPO/MTP-to-LC cassettes and enclosures for structured breakouts.
Huawellux's specification for MPO and MTP® assemblies (identical for both) is insertion loss ≤0.35 dB for single-mode and multimode, with return loss >60 dB single-mode (OS2, APC) and >30 dB multimode (OM3/OM4/OM5). LC and SC patch cords are listed at insertion loss ≤0.35 dB and return loss ≥50 dB (single-mode UPC), ≥60 dB (single-mode APC) and >30 dB (multimode). Every Huawellux product receives end-face visual inspection under a 400x video microscope and is tested for insertion loss (IL) and return loss (RL) before it ships. Interferometric end-face geometry (fiber height, coplanarity, end-face angle and radius) is checked by sample-based testing in standard production, and 100% interferometer testing of a batch is available on request. Dust caps are fitted on every connector, and a formal test report is available on request.
Frequently Asked Questions
What is an 800G breakout cable?
A cable that splits one 800G parallel port into lower-speed ports: two 400G (1x2) using an MPO-16 to 2× MPO-12 assembly, or eight 100G (1x8) using an MPO-16 to 8× LC duplex harness.
How do I break out 400G to 4x100G?
Use a 400G DR4 module with an 8-fiber MPO-12 APC to 4× LC duplex harness, connected to four 100G DR single-lane modules. Configure the switch port for 4×100G breakout.
Can a 400G FR4 module be broken out?
No. FR4 and LR4 multiplex four wavelengths onto one fiber pair, so they cannot be split with a cable. Use DR4 or SR4-type parallel optics for breakout.
Which fibers pair together in an MPO to LC breakout?
For a 400G DR4 MPO-12, fibers 1/12, 2/11, 3/10 and 4/9 form the four duplex pairs. For an MPO-16, fibers 1/16, 2/15 and so on to 8/9.
Should I use a direct harness or a cassette?
A direct harness for short in-rack or adjacent-rack links; a trunk with MPO-to-LC cassettes for longer runs and frequent changes, after checking the loss budget.
