1.6T Optics and Cabling: OSFP-XD, 2xDR4, DR8 and MPO-16 APC
A 1.6T DR8 or 2xDR4 module sends 8 lanes of 200G over 16 single-mode fibers (8 Tx, 8 Rx), for 500 m or 2 km. On the module face it has either two MPO-12/APC ports (8 fibers used in each) or one MPO-16/APC port. Dual MPO-12 modules use two standard 8-fiber MPO-12/APC Type B cords and can break out to two 800G DR4 ports. MPO-16 modules need MPO-16/APC cords, or an MPO-16 to 2× MPO-12 harness for breakout. OSFP1600 is an 8 × 200G form factor; OSFP-XD is a separate 16-lane form factor.
Form Factors: OSFP1600 vs OSFP-XD
| OSFP1600 | OSFP-XD | |
|---|---|---|
| Electrical lanes | 8 × 200G | 16 × 100G (1.6T); 16 × 200G planned (3.2T) |
| Compatibility | Backward compatible with OSFP800 | Separate, wider 16-lane form factor |
| Optical ports defined | Dual MPO-12, MPO-16 and others | Dual MPO-12, MPO-16, MPO-12 two-row, dual small-form-factor connectors |
| Typical 1.6T fiber module | DR8 / 2xDR4 (500 m), DR8-2 / 2xDR4-2 (2 km) | 16-lane designs, depending on the module |
Both come from the OSFP MSA. The MSA white paper gives switch examples: 32 OSFP1600 ports in 1RU for 51.2T and 64 ports in 2RU for 102.4T. For cabling, the module type and its port matter more than the cage: always read the optical connector from the module datasheet.
DR8 vs 2xDR4: Same Fibers, Different Use
The optics are the same: 8 transmit lanes and 8 receive lanes at 200G on parallel single-mode fiber. The difference is how the host uses them:
- DR8 runs as one 1.6T port to another DR8 module.
- 2xDR4 runs as two independent 800G ports. Each half can link to a separate 800G DR4 module.
The suffix "-2" or "+" means the 2 km version; without it, 500 m.
The Two Port Styles and Their Lane Maps
The OSFP MSA lane maps (male MPO receptacle on the module, viewed at the module face):
| Port | Positions 1–4 | 5–8 | 9–12 | 13–16 |
|---|---|---|---|---|
| Each MPO-12 (×2) | Tx1–Tx4 | unused | Rx4–Rx1 | – |
| MPO-16 | Tx1–Tx4 | Tx5–Tx8 | Rx8–Rx5 | Rx4–Rx1 |
Two consequences for the cable:
- Both maps are "Tx from the left, Rx mirrored from the right". A Type B cord (position 1 to 12, or 1 to 16) connects Tx1 to Rx1 on the far module. This is a derived reading of the lane maps; confirm polarity in the cable drawing. See MPO polarity.
- MPO-16 does not mate with MPO-12. MPO-16 (TIA-604-18) uses a different guide-pin size and spacing and an offset key. Panels, adapters and cords must all be MPO-16. See 800G MPO-16 link design.
Which Cable for Which Link
| Link | Cable | Polarity |
|---|---|---|
| DR8 (2× MPO-12) ↔ DR8 (2× MPO-12) | Two MPO-12/APC female cords, 8 fibers used (Base-8 or 12-fiber) | Type B |
| DR8 (MPO-16) ↔ DR8 (MPO-16) | One MPO-16/APC female cord, 16 fibers | Type B |
| 2xDR4 (2× MPO-12) ↔ 2 × 800G DR4 | Two MPO-12/APC female cords, one to each 800G module | Type B |
| 2xDR4 (MPO-16) ↔ 2 × 800G DR4 | MPO-16/APC to 2× MPO-12/APC breakout harness, 8 fibers per leg | Mapping per drawing |
| Mixed (MPO-16 module ↔ dual MPO-12 module) | MPO-16 to 2× MPO-12 harness or a conversion cassette | Mapping per drawing |
For structured links, the same rules apply through the panels: APC throughout, OS2 fiber, and trunks with the same connector family as the module port. Use Base-8 trunks for dual MPO-12 modules and MPO-16 trunks for MPO-16 modules.
Ordering Checklist
| Item | Example |
|---|---|
| Module and port | 1.6T DR8, OSFP1600, 2× MPO-12/APC |
| Connector and gender | MPO-12/APC female both ends |
| Fibers per connector | 8 (Base-8) or 12 |
| Fiber | OS2 single-mode |
| Polarity | Type B |
| Breakout legs | 2 legs, 8 fibers each, leg labels A/B |
| Length and jacket | Per link; see the trunk length guide |
For the standard behind these modules, see IEEE 802.3dj and 1.6T Ethernet. For 400G and 800G modules, see the transceiver cabling map.
Related reading: how 1.6T fits the wider picture is covered in data center fiber trends for 2026, and optical circuit switches explains how some operators reconfigure spine links without re-cabling.
Next generation: 3.2T is expected to keep 16 fibers per port; see 3.2T Ethernet outlook (standards in progress).
Frequently Asked Questions
How many fibers does a 1.6T DR8 module use?
16 single-mode fibers: 8 transmit and 8 receive, at 200G per lane.
What is the difference between 1.6T DR8 and 2xDR4?
The optics are the same. DR8 runs as one 1.6T port; 2xDR4 runs as two 800G ports that can connect to two separate 800G DR4 modules.
Can I plug an MPO-12 cord into an MPO-16 module?
No. MPO-16 has a different guide-pin layout and an offset key. Use an MPO-16 cord or an MPO-16 to 2× MPO-12 harness.
Is OSFP-XD the same as OSFP1600?
No. OSFP1600 has 8 electrical lanes at 200G and is backward compatible with OSFP800. OSFP-XD is a separate form factor with 16 electrical lanes.
What polarity do 1.6T DR8 links use?
Based on the MSA lane maps, a Type B cord connects Tx1 to Rx1 for both dual MPO-12 and MPO-16 ports. Confirm in the cable drawing.
