OS2 Trunks for DCI and Campus Links: Outdoor Cable, Loss and Ordering
A link between two buildings has three sections: indoor cabling in building A, an outside plant (OSP) cable between the buildings, and indoor cabling in building B. Use OS2 single-mode for all three. The outdoor section needs outdoor-rated cable (water-blocked, UV-resistant, armored or duct-rated as the route requires); the indoor sections need listed indoor cable such as OFNR or OFNP. In the US, unlisted outdoor cable may run only about 15 m (50 ft) inside a building before it transitions to listed cable or enters a raceway. At campus and DCI distances, use duplex WDM optics such as FR4 or LR4, and budget connectors carefully: on a 10 km link, connector grade and the number of patch points decide whether it passes.
Scope of this guide: links between buildings, from a few hundred metres to about 10 km. For OS2 vs multimode inside the data hall see OS2 vs OM3 vs OM4 vs OM5; for indoor jacket ratings see OFNP vs OFNR vs LSZH.
The Three Sections of a Campus or DCI Link
| Section | Cable | Terminations |
|---|---|---|
| Building A: switch to entrance | Indoor OS2 MPO trunk or LC cords, OFNR/OFNP/LSZH | MPO or LC at both ends |
| Between buildings | Outdoor OS2 cable (loose tube, water-blocked; armored, dielectric or aerial as the route needs) | Spliced or pre-terminated at each entrance |
| Building B: entrance to switch | Indoor OS2 MPO trunk or LC cords | MPO or LC at both ends |
The transition happens at an entrance facility: a splice enclosure or patch panel close to where the outdoor cable enters. In the US, the National Electrical Code (NEC Article 770) limits unlisted outside plant cable to about 15 m (50 ft) inside the building unless it runs in a suitable raceway. Check local codes elsewhere.
Which Optics: Parallel or Duplex?
Parallel single-mode optics such as 400G DR4 use MPO and reach 500 m. Beyond that, most links use duplex WDM optics on LC: 400G FR4 to 2 km and 100G LR4 or 400G LR4 to 10 km. That makes the outdoor cable a count of duplex pairs, and it is why an MPO trunk inside the building often ends in an MPO-to-LC cassette or breakout at the entrance. See transceiver cabling map.
Loss Budget: Two Worked Examples
Values used. TIA maximums (ANSI/TIA-568.3-D): outside plant single-mode cable 0.5 dB/km and inside plant cable 1.0 dB/km at 1310 nm; mated connector pair 0.75 dB; splice 0.3 dB. Spec-grade parts: OS2 cable at 0.4 dB/km (the ISO/IEC 11801 OS2 cabled-fiber value; TIA-568.3-D itself allows 0.5 dB/km for outside plant), 0.35 dB per mated pair (Huawellux specification) and 0.1 dB per fusion splice (typical). Each link has 100 m of indoor cable at each end (0.2 km total). Channel limits are the maximum channel insertion loss in IEEE 802.3: 4.0 dB for 400GBASE-FR4 (2 km) and 6.3 dB for 100GBASE-LR4 (10 km). The connections in the transceiver ports are not counted.
400G FR4, 2 km outdoor + 0.2 km indoor, limit 4.0 dB. Four mated pairs (a patch panel and an entrance panel in each building) and two splices (one at each entrance).
| Item | Calculation | Spec-grade parts | TIA maximums |
|---|---|---|---|
| Outdoor fiber | 2 km × 0.4 dB/km (spec) / 2 km × 0.5 dB/km (TIA) | 0.80 dB | 1.00 dB |
| Indoor fiber | 0.2 km × 1.0 dB/km | 0.20 dB | 0.20 dB |
| Mated pairs | 4 × 0.35 / 4 × 0.75 | 1.40 dB | 3.00 dB |
| Splices | 2 × 0.1 / 2 × 0.3 | 0.20 dB | 0.60 dB |
| Total | 2.60 dB, pass (1.40 dB margin) | 4.80 dB, fail (0.80 dB over) |
100G LR4, 10 km outdoor + 0.2 km indoor, limit 6.3 dB. Fiber, spec-grade: 10 × 0.4 + 0.2 × 1.0 = 4.00 + 0.20 = 4.20 dB. Fiber, TIA maximum: 10 × 0.5 + 0.2 × 1.0 = 5.00 + 0.20 = 5.20 dB. Two splices in every case.
| Design | Calculation | Spec-grade parts | TIA maximums |
|---|---|---|---|
| 4 mated pairs, 2 splices | 4.20 + 1.40 + 0.20 / 5.20 + 3.00 + 0.60 | 5.80 dB, pass (0.50 dB margin) | 8.80 dB, fail (2.50 dB over) |
| 2 mated pairs, 2 splices | 4.20 + 0.70 + 0.20 / 5.20 + 1.50 + 0.60 | 5.10 dB, pass (1.20 dB margin) | 7.30 dB, fail (1.00 dB over) |
If the outdoor cable is only guaranteed to the TIA-568.3-D 0.5 dB/km rather than 0.4 dB/km, add 0.1 dB per km to the spec-grade column: +0.2 dB on the FR4 example and +1.0 dB on the LR4 example, which puts the 4-pair spec-grade LR4 design at 6.80 dB, over the limit.
These are example calculations; check the module data sheet. On long links, fiber loss dominates, so remove patch points rather than chase lower connector loss. See MPO insertion loss budget.
Choosing the Outdoor Cable
- Duct: dielectric loose-tube cable, water-blocked (gel or dry).
- Direct burial or rodent risk: armored cable, often with an extra jacket.
- Aerial: self-supporting or lashed cable rated for the span.
- Indoor/outdoor: a cable rated for both can run through the building without a transition, if its listing meets the local code.
Bend-insensitive G.657.A1 fiber helps in tight trays and enclosures at each end. See bend-insensitive fiber.
Splice or Pre-Terminate?
Long outdoor cables are usually pulled bare and fusion spliced to pigtails at each entrance, because connectors would not survive the pull. Short campus runs can use pre-terminated cable with a pulling grip. Inside each building, factory-made MPO trunks save time and come with test reports. See preterminated vs field-terminated fiber.
Ordering Checklist
| Item | What to specify |
|---|---|
| Route | Distance per section, duct, burial or aerial |
| Optics | DR4, FR4 or LR4; this sets fiber count and connector type |
| Fiber count | Duplex pairs needed, plus spares |
| Indoor sections | MPO or LC, polarity, gender, length, jacket rating |
| Transition | Splice enclosure or patch panel at each entrance |
| Testing | OTDR on the outdoor cable; insertion loss on each indoor assembly |
Very high fiber counts: for 1,728 to 6,912 fibers in one outdoor cable, see rollable ribbon fiber cable.
Frequently Asked Questions
Can I use indoor OS2 trunk cable between buildings?
No. Outdoor runs need outdoor-rated cable that is water-blocked and UV-resistant. Indoor cable is not built for moisture or temperature swings.
How far can outdoor fiber cable run inside a building?
In the US, NEC Article 770 allows unlisted outside plant cable about 15 m (50 ft) inside the building before it transitions to listed cable, unless it runs in a suitable raceway.
What optics are used for campus and DCI links?
Parallel DR4 reaches 500 m on MPO. Longer links usually use duplex FR4 (2 km) or LR4 (10 km) on LC connectors.
How many patch panels can a 10 km LR4 link have?
In the example, OS2 fiber at 0.4 dB/km (ISO/IEC 11801) uses 4.2 dB of the 6.3 dB budget, and four mated pairs pass at 5.80 dB with 0.35 dB connectors. At TIA-568.3-D maximums (0.5 dB/km outside plant, 0.75 dB per pair) fiber uses 5.2 dB and the link fails at 8.80 dB with four pairs or 7.30 dB with two. Use low-loss connectors and as few patch points as possible.
Should the outdoor cable be spliced or pre-terminated?
Long cables are usually spliced to pigtails at each entrance. Short runs can be pre-terminated with a pulling grip.
Does Huawellux supply outdoor OS2 cable?
Yes. Huawellux supplies outdoor OS2 single-mode cable for campus and DCI routes, together with the indoor assemblies. Send the route details (fiber count, length, installation method) and the cable construction is confirmed in the quotation.
